Product description
1 12345678910111213141516
© 2022 KOSTAL Solar Electric GmbH21
2.4Wallbox structure
The housing is in two parts and consists of the lower part of housing and the housing
cover.
1Housing cover
2Lower part of housing
3LED display
4Charging cable
5Cable inlets (there are further cable inlets on the top and bottom)
6Connection panel (terminal strip)
7Control unit
8DIP switch
Cable holder
The wallbox is designed so that the charging cable can be hung on the housing itself.
