6.3Example of DIP setting depending on
application
NOTE
Bank 2 (S2): If the values for your installation deviate from this example, e.g. for a house
connection fuse of only 50 A, this must be adapted using the DIP switches.
Settings for bank 2 (S2) in this example:
■ The maximum charging current per phase is set to 16A (bank2/ DIP1-3).
■ The maximum current for the house connection is set to 63A (bank2/ DIP6-8).
ENECTOR without energy meter
KSEM
LAN
L1 L2 L3
L1 L2 L3 N
LAN
STATUS
NETWORK
SERIAL BUS
REST
Smart Energy Meter
ON
OFF
1245 367
8
ON
Bank 2 (S2)
63 A
3x16 A
11 kW
1245 367
8
ON
Bank 1 (S1)
ON
OFF
BankDIP switch
87654321
2OFFOFFOFFOFFOFFOFFOFFOFF
1OFFOFFOFFOFFOFFOFFOFFOFF
ENECTOR with KOSTAL Smart Energy Meter and convenience functions
KSEM
LAN
L1 L2 L3
L1 L2 L3 N
LAN
STATUS
NETWORK
SERIAL BUS
REST
Smart Energy Meter
1245 367
8
ON
ON
OFF
1245 367
8
ON
Bank 2 (S2)
63 A
3x16 A
11 kW
Bank 1 (S1)
ON
OFF
BankDIP switch
87654321
2OFFOFFOFFOFFOFFOFFOFFOFF
