Setting up wallbox in the KSEM
1 12345678910111213141516
© 2022 KOSTAL Solar Electric GmbH78
7.3ENECTOR with KOSTAL Smart Energy Meter
for blackout protection (house connection
monitoring)
If the ENECTOR is connected to a KOSTAL Smart Energy Meter and this is only to be used
for blackout protection (house connection monitoring), the RS485 interface used must be
configured in the KOSTAL Smart Energy Meter.
Only then can the ENECTOR read data from the KOSTAL Smart Energy Meter.
Do this by performing the following steps:
1.Call up the online interface of the KOSTAL Smart Energy Meter.
2.Call up the Modbus configuration under Modbus settings .
3.Activate the RS485 interface connected to the ENECTOR (e.g. RS485 B) .
Select the User-defined value under Presettings and configure the following settings
under Advanced.
ParameterValue
InterfaceRS485 B
PresettingUser-defined
ModeSlave
Slave address2
Baud rate57600
Data bits8
ParityNone
Stop bit2
1.Press the Save button to adopt the settings.
✔ The interface to the ENECTOR has been set up in the KOSTAL Smart Energy Meter.
