Commissioning/configuration
1 12345678910111213141516
© 2022 KOSTAL Solar Electric GmbH65
BankDIP switchFunction
ONKOSTAL Smart Energy Meter as energy manager (mas-
ter) with activation code
Activating convenience functions for KSEM
If a PV system is present and if used in combination with the KOSTAL Smart Energy
Meter and an activation code, the electric vehicle can be charged using the solar power
generated.
NOTE
In order for the wallbox to be set up with the convenience functions in the KOSTAL
Smart Energy Meter (KSEM), this function must first be activated via an activation code
for the wallbox in the KSEM.
The activation code can be purchased from the KOSTAL Solar online shop.
To access the shop, go to:
shop.kostal-solar-electric.com.
The functions can be controlled via the KSEM.
These include:
■ Power Mode (simple charging)
■ Solar Power Mode (solar charging)
■ Solar Plus Mode (solar-optimised charging)
■ Lock Mode (lock wallbox)
Configure the setting as desired.
Bank 2
Bank 1
12
45
3
678
ON
1245 36
78
ON
7564
ON
OFF
Bank 1
1245 367
8
ON
Comfort function
Configurable functions:
BankDIP switchFunction
17ONConvenience functions (solar charging) activated in
combination with the KSEM
6ON
