DSP-62-AEC, DSP-62-UC – Protocol 3000
62
Function
Description
Syntax
Parameters/Attributes
Example
DSP-EQ
Set DSP equalizer.
COMMAND
#DSP-
EQfield_id,<direction_type>.<port_type>.<port_index>.<s
ignal_type>.<index>,band,value<CR>
FEEDBACK
~nn@DSP-EQfield_id,<direction_type>.<port_type>.<port_in
dex>.<signal_type>.<index>,band,value<CR><LF>
Field_id
o level
O freq
O qfactor
O band-bypass
<direction_type> –
o IN
o OUT
▪<port_type> –
For IN
o ANALOG_STEREO
o ANALOG_AUDIO
o USB_B
For OUT
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
band –
For IN
1 to 4
For OUT
1 to 8
For bypass
0– global bypass
1,2,3,4 – for each band
value –
For level [dB]
-24 to +24
For freq [Hz]
20 to 20K
For qfactor [Oct]
0.05 to 4
For bypass [ms]
0– off
1 – on
Set EQ level on input 2 to 12:
#DSP-EQlevel,IN.ANALOG_
AUDIO.2.AUDIO.1,?,12<CR>
DSP-EQ?
Set DSP equalizer.
COMMAND
#DSP-
EQ?field_id,<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,band<CR>
FEEDBACK
~nn@DSP-EQfield_id,<direction_type>.<port_type>.<port_in
dex>.<signal_type>.<index>,band,value<CR><LF>
Field_id
o Level
o Freq
o Qfactor
o Band-bypass
<direction_type> –
o IN
o OUT
▪<port_type> –
For IN
o ANALOG_STEREO
o ANALOG_AUDIO
o USB_B
For OUT
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
band –
For IN
1 to 4
For OUT
1 to 8
For band-bypass
0– global bypass
1,2,3,4 – for each band
value –
For level [dB]
-24 to +24
For freq [Hz]
20 to 20K
For qfactor [Oct]
0.05 to 4
For bypass [ms]
0– off
1 – on
Get global bypass state for EQ
on input 2:
#DSP-EQ?bypass,IN.ANALO
G_AUDIO.2.AUDIO.1,0<CR>
