Kramer Electronics Ltd.
DSP-62-AEC, DSP-62-UC – Protocol 3000
63
Function
Description
Syntax
Parameters/Attributes
Example
DSP-EXP
Set DSP expander.
COMMAND
#DSP-
EXPfield_id,<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-EXPfield_id,<direction_type>.<port_type>.<port_i
ndex>.<signal_type>.<index>,value<CR><LF>
Field_id
o Attack
o Release
o Threshold
o Ratio
o Bypass
<direction_type> – IN
<port_type> –
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
<port_index> – The port number
as printed on the front or rear panel
For ANALOG_AUDIO – 2 to 5
For USB_B, ANALOG_STEREO – 1
<signal_type> –
o AUDIO
<index> – 1
value –
For attack [ms]
0 to 100
For release time [ms]
0 to 10K
For threshold [dB]
-100 to 0
For ratio
[1 to 100]:1
For gain compensation [dB]
-100 to +15
For bypass [ms]
0– off
1 – on
Set attack time on input 2 to
50:
#DSP-EXPattack,IN.ANALO
G_AUDIO.2.AUDIO.1,50<CR
>
DSP-EXP?
Get DSP expander.
COMMAND
#DSP-
EXP?field_id,<direction_type>.<port_type>.<port_index>.
<signal_type>.<index><CR>
FEEDBACK
~nn@DSP-EXPfield_id,<direction_type>.<port_type>.<port_i
ndex>.<signal_type>.<index>,value<CR><LF>
Field_id
o Attack
o Release
o Threshold
o Ratio
o Bypass
<direction_type> – IN
<port_type> –
o ANALOG_AUDIO
o ANALOG_STEREO
o USB_B
<port_index> – The port number
as printed on the front or rear panel
For ANALOG_AUDIO – 2 to 5
For USB_B, ANALOG_STEREO – 1
<signal_type> –
o AUDIO
<index> – 1
value –
For attack [ms]
0 to 100
For release [ms]
0 to 10K
For threshold [dB]
-100 to 0
For ratio
1 to 100:1
For bypass
0– off
1 – on
Get attack time on input 2:
#DSP-EXP?attack,IN.ANAL
OG_AUDIO.2.AUDIO.1<CR>
DSP-HPF
Set DSP HPF.
COMMAND
#DSP-
HPFfield_id,<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-HPFfield_id,<direction_type>.<port_type>.<port_i
ndex>.<signal_type>.<index>,value<CR><LF>
Field_id
o freq
o bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
For freq [Hz]
20 to 20K
For bypass
0– off
1 – on
Set bypass status on input 2 to
off:
#DSP-HPFbypass,IN.ANALO
G_AUDIO.2.AUDIO.1,0<CR>
