Kramer Electronics Ltd.
DSP-62-AEC, DSP-62-UC – Protocol 3000
64
Function
Description
Syntax
Parameters/Attributes
Example
DSP-HPF?
Get DSP HPF.
COMMAND
#DSP-
HPF?field_id,<direction_type>.<port_type>.<port_index>.<
signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-HPFfield_id,<direction_type>.<port_type>.<port_i
ndex>.<signal_type>.<index>,value<CR><LF>
Field_id
o freq
o bypass
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
For freq [Hz]
20 to 20K
For bypass
0– off
1 – on
Get bypass status on input 2:
#DSP-HPF?bypass,IN.ANAL
OG_AUDIO.2.AUDIO.1<CR>
DSP-INVERT
Set DSP phase
inversion state.
COMMAND
#DSP-
INVERT<direction_type>.<port_type>.<port_index>.<signal
_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-INVERT<direction_type>.<port_type>.<port_index>.
<signal_type>.<index>,value<CR><LF>
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
0– off
1 – on
Set phase inversion state input
2 to off:
#DSP-INVERTIN.ANALOG_A
UDIO.2.AUDIO.1,0<CR>
DSP-INVERT?
Get DSP phase
inversion state.
COMMAND
#DSP-
INVERT?<direction_type>.<port_type>.<port_index>.<signa
l_type>.<index><CR>
FEEDBACK
~nn@DSP-INVERT<direction_type>.<port_type>.<port_index>.
<signal_type>.<index>,value<CR><LF>
<direction_type> – IN
▪<port_type> –
o ANALOG_AUDIO
▪<port_index> – The port number
as printed on the front or rear
panel
2 to 5
▪<signal_type> –
o AUDIO
▪<index> – 1
value –
0– off
1 – on
Get phase inversion state on
input 2:
#DSP-INVERT?IN.ANALOG_
AUDIO.2.AUDIO.1<CR>
DSP-LIMITER
Set DSP limiter.
COMMAND
#DSP-
LIMITERfield_id,<direction_type>.<port_type>.<port_index
>.<signal_type>.<index>,value<CR>
FEEDBACK
~nn@DSP-LIMITERfield_id,<direction_type>.<port_type>.<po
rt_index>.<signal_type>.<index>,value<CR><LF>
Field_id
o Threshold
o Bypass
<direction_type> – OUT
▪<port_type> –
o ANALOG_STEREO
o USB_B
▪<port_index> – The port number
as printed on the front or rear
panel
1
▪<signal_type> –
o AUDIO
▪<index> – 1 to 2
value –
For threshold [dB]
-100 to 0
For bypass
0– Off
1 – On
Set bypass status on output to
ON:
#DSP-LIMITERbypass,OUT.
ANALOG_STEREO.1.AUDIO.1
,1<CR>
