4. Configure a command as follows:
▪ Enter a device command (for example, mute).
▪ Enter the command description.
▪ Select a trigger from the drop-down box to carry out the command (Clock, No Clock,
5V, No 5V, Button On, Button Off, Remote On, Remote Off, Toggle On or Toggle
Off).
▪ Enter a delay time, if required.
▪ Check Hex for command Hex format, if required.
▪ Check Enable to enable the command.
Figure 75: RS-232 – Creating a Command
5. Click Add.
Figure 76: RS-232 Page – Command Added
6. You can:
▪ Click Delete to delete the command.
▪ Click Test to test the command.
▪ Change any of the command configurations.
▪ Enable or disable the command.
