KDS-8-MNGR – Using Embedded Web Pages
50
2. Click and drag a decoder/group of decoders/all decoders (Rx All) from the Receiver area
to a resolution button in the Resolution area.
Selecting “Bypass” forces that decoder to output all routed sources in their native resolutions.
You can also drag and drop resolutions onto decoders to change their output resolution.
Output resolution is set.
Configuring Video Walls
Configure or modify video walls of up to 8x8 using multiple decoders in a group.
To configure a video wall:
1. In the Menu tabs, select Video Wall. The Video Wall page appears.
Figure 42: Video Wall Page
2. Click to create a new Video Wall group.
Click to edit an existing video wall group.
Click to delete a group
3. Enter group details:
▪ Next to Order, open the drop-down box to select the video wall group order (also use
to change the order of existing groups).
Video wall groups are displayed in the Monitor & Control tab in the same order.
▪ Enter Group Name.
▪ Select the encoder to use as the video source for the video wall.
