d. Click mouse in User Name text box. On-screen keyboard opens.
e. Enter the User Name (admin, by default).
f. Move cursor to Password text box.
g. Enter the Password (admin, by-default).
h. Click Enter.
3. Change Network settings as desired.
Discovered IP address can be used to access embedded web pages online.
Monitoring and Controlling Decoders and Encoders
The Monitor & Control tab provides easy to use drag-and-drop control over all basic routing
functions of the KDS-8 encoders and decoders that have been detected within the local
network and enables performing the following actions:
• Routing Video on page 15.
• Routing a Video Wall on page 17.
• Routing a Multi-viewer on page 18.
• Routing HDMI Audio on page 19.
• Routing Analog Audio on page 22.
• Pairing USB Hosts and Devices on page 24.
• Routing IR Signals on page 26.
• Routing RS-232 Signals on page 27.
• Activating a Macro on page 29.
In all the sections (except for the Routing Video section), transmitters (encoders) are
represented by the source icon ( ) and receivers (decoders) are represented by the display
icon ( ). Each of this tab’s sections control the routing of a different type of interface of
KDS-8 and KDS-8F.
Units that were previously a part of the system, but are not currently detected will still be
displayed, however they will have a disconnected icon ( ) and cannot be used for routing.
