KDS-8-MNGR – Using Embedded Web Pages
Routing Video
Drag and drop detected encoders and decoders to control video routing in the system.
The Video page includes two main areas. The:
• Video Transmitter area, which includes drag-and-drop depiction buttons for all the
encoders that are detected by the system, and a multi-option stop button to stop video
transmission.
• Video Receiver area, which includes drag-and-drop depiction buttons for all the
decoders that are detected by the system, and a Stop button to stop one or all output
streams from being displayed.
Each encoder and decoder box is depicted as a small-sized, low-framerate, video thumbnail
indicating which video is currently active, or can be represented as follows to indicate that:
The encoder is in the video wall mode.
The encoder is in the Multiviewer mode.
The encoder current input has no live source connected.
The decoder does not have an active display connected.
The encoder/decoder does not support the video thumbnail feature.
The encoders’ source streams are collectively exceed the 10Gbps bandwidth
limitation.
The encoder/decoder is offline or currently not detected by KDS-8-MNGR.
KDS-8-MNGR features automatic bandwidth reduction if the total source streaming exceeds
10Gbps. In case this happens, we recommend that you reduce the source resolution, frame
rate or bit depth to maintain stable video quality on the display.
The Video page enables performing the following actions:
• Streaming an HDMI Audio Source to a Single Decoder on page 20.
• Streaming an HDMI Audio Source to Multiple Decoders on page 21.
• Stopping an HDMI Audio Source Stream on page 21.
• Stopping an HDMI Audio Display Stream on page 21.
