Kramer VW-4 User Manual

Kramer Electronics Ltd.
VW-4 – Connecting VW-4
8
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in Figure 3.
Figure 3: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears as shown in
Figure 4 or Figure 5.
Figure 4: Internet Protocol Version 4 Properties Window

Kramer VW-4 Specifications

General

Product color	Black
Built-in display	No
RS-232/422 connector	Yes
HDMI input ports quantity	1
HDMI output ports quantity	5
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
HDCP version	2.2
Maximum refresh rate	60 Hz
Input voltage	5 V
Power supply location	External

Weight and Dimensions

Depth	195 mm
Width	190 mm
Height	27 mm
Weight	900 g
Package depth	212 mm
Package width	351 mm
Package height	72 mm
Package weight	1400 g
