IC 40 function > Inputs > Analogue
Priority and running time in operating modes 1 – 10
In operating modes 1 to 10, the actuator is positioned (0 –
100%) by both digital inputs DI 1 and DI 2. Alternatively, on
the IC 40A..A, there is the option of positioning the actuator
with a 4 – 20 mA current signal. Simultaneous presets via the
analogue input and via the digital inputs necessitate
defining a priority in BCSoft®. The digital inputs have priority
by default.
Opening speeds and closing speeds between 0 and 25.5 s
can be set for analogue mode. The time always relates to
the distance between the positions at 4 and 20 mA. If the
current signal changes more slowly than the set running
time, the actuator follows more slowly accordingly through
to step-by-step movement, see page 23 (Running times).
58
