Start-up
28
Pos: 16.16 /BA/Sic herheit/Hydr aulik/Achtung - V erschmutzung d er Hydrauli kanlage @ 2\mod _1202393336 803_78.docx @ 59 155 @ @ 1
Caution! - Soiling of the hydraulic system
Effect: Damages to the machine
• When connecting the quick couplings, ensure that these are clean and dry.
• Note chafing areas or points of contact.
Pos: 16.17 /BA/Sic herheit/Betätig ungsseil/Betätig ungsseil verlege n @ 8\mod_1 219298996457 _78.docx @ 111447 @ 2 @ 1
Danger! - Unintended actions triggered.
Effect: Danger to life, injuries or damage to the machine.
• The actuating rope must be routed in such a way that no movements are unintentionally
triggered in any transport or working positions.
• The actuating rope must not come into contact with the tractor tyres
• Note chafing areas or points of contact.
Pos: 16.18 /BA/I nbetriebnahme/ EasyCut/Hydra ulik/Hydrauli kanschluss Bild EC 320N eue Generatio n @ 58\ mod_129665829046 3_78.docx @ 5 52744 @ 2 @ 1
EC-330-0
3
1
Fig. 7
Pos: 16.19 /BA/I nbetriebnahme/ EasyCut/Hydra ulik/Steuergerä t 1xEW @ 10\ mod_1221486740 745_78.doc x@ 1 34020 @ 3 @ 1
A single-action control unit is required on the tractor to operate the machine.
Pos: 16.20 /BA/I nbetriebnahme/ EasyCut/Hydra ulik/Anschluss H ydraulikleitung EC 280/320 @ 9 \mod_1220872 203313_78. docx@ 128204 @ @ 1
Single-action control unit (1) (red1):
• (1) red= - lift/lower mowing unit
Pos: 16.21 /BA/I nbetriebnahme/ EasyCut/Hydra ulik/Betätigungss eil ablegen @ 1 0\mod_122 1487480261_78.d ocx @ 134042 @ 3 @ 1
• The actuating rope (3) can be set down in a suitable place in the tractor cab.
Pos: 16.22 /BA/--- ------ ------Seitenumbruch---- ------------ @ 0\m od_1196175311 226_0.docx @ 4 165 @ @ 1
