IV - 3
Adjusting the swather
4.7 Adjustable throttles
The adjustable throttle (1) can be used to set the speed
at which the offset drawbar is lowered and lifted.
• Unscrew the hexagonal nut (a).
• Screw the stud bolt (b) in or out
(screwing in will reduce the
oil flow and thus causes a slower lift or lowering of the
offset drawbar).
SW46T030
1
a/b
