I - 2
General Information
1.2.6 Proper Use
The Swadro rotary windrower is designed exclusively for
usual applications during agricultural work (proper use).
Any further use is considered to be improper use. The
manufacturer is not liable for any damage resulting from
such use. Such use is solely at the operator's risk.
Part of the proper use is the adherence to the operating,
maintenance and repair instructions specified by the
manufacturer.
1.2.7 General Specifications
Driving on roads is only permissible with the swath arms in
the transport position.
Type Swadro 46 T
Draw bar standard
Tandem axle standard
Number of arms Piece 13
Number of double tines Piece 4
Working width approx. mm 4600
Swath disc diameter approx. mm 3600
Height in transport position [H] approx. mm 2700
Height in operating position approx. mm 1200
Length [L] approx. mm 5100
Width in transport position [B] approx. mm 2580
Maximum width in operating position approx. mm 4600
Power requirement app. kW/PS 37/50
PTO shaft speed max. permitted drive speed 1/min. max. 540 U/min
PTO shaft speed recommended operating drive speed 1/min max. 350-450 U/min
Equivalent continous sound pressure level below 70 dB(A)
Acreage capacity ca./h 5,5-6
Tyres 18 x 8,50-8 6PR
Tyre pressure bar 1.0
lighting voltage Volt 12
max. permitted transport speed bar 200
Weight of machine [kg] 720
