VI - 1
Lubrication
Before correcting any operational
faults or carrying out any repair,
maintenance or cleaning work, always
disengage the driving system, stop the
engine and remove the key from the
ignition!
6 Lubrication
Use vegetable-based oils and grease.
Lubricant Quantities and Designations for the Gearboxes
Bio-Lubricants
1
2
SW46T020_1
The main gears on the rotary swather is prelubricated for
their entire service life and are therefore completely
maintenance-free!
Quantity lit Designation/Brand Designation/Brand
Rotor gearbox 0,5 completely maintenance-free
on request
6.1 Bearing surfaces on the rotary
swather
20h
SW700027
8h
20h
20h
20h
20h
40h
40h
Lubricate PTO shaft with a multipurpose grease at the
intervals shown in the figure. Observe the operating manual
provided by the PTO shaft manufacturer.
6.2 PTO shaft
