R E P A I R S
5 R E P A I R S
Thecomponentsofthecoffeemachinearemostlyconnectedwithlatches,meaning
withoutscrews.
Whenlooseningtheseconnection s,proceedw ithcareandpatiencet oavoid
causinganydamage.
Designationofspareparts
Thecomponentsinthefollowingillustrationsareindexedwithpositionnumbers.The
correspondingdesignationandsparepartnumberarelistedinsection"Spareparts"on
page40.
5.1 Toolsandac cessories
Withthefollowingassortmentoftools,allrepairsdescribedcanbemade.
5.2 Generaldisassembly
Generaldisassembly
 givesaccesstotheimportantmachinecomponents
 isrequiredforthefollowingrepairinstructions.
Dependingontherepairdonethemachinedoesnothavetobefullydisassembled.
This section con-
tains special safety
and assembly notices.
Disregarding them may
lead to injuries and dam-
ages.
• Ovalscrewdriver
• TORXscrewdriver
(TX6,TX10,TX20,TX25)
• Screwdriverwithapprox.4mmtooltip
• HexagonalwrenchSW4
• FlatwrenchSW14,10mmAF
• Torquewrench
• Longnosedpliers
• Beakerandtoweltocatchandwipe
awayleakingwater
If necessary empty
the water system
first (see page 12).
Before disassembly,
disconnect the
mains plug - the coffee
machine must be voltage
free.
