R E P A I R S
8. Placetheclosinghandle(56)intheverticalpositionandremovethecoverlid(57).
9. Removethecoffeetap(24).
10. Removethecompactbrewingunit(58),loosenthefourscrews(55)andplacethe
compactbrewingunitononeside.
11. Removethedriptray(59):Loosenthetwolockinglatchesonbothsides(f)ofthe
capsulebaymanually.
12. Removethecuptrayorheatingplate(42)(dependsonmachinetype):
Ifremovingheatingplate,loosenthescrew(3)ofthegroundingconnectionfirst.
Pushthetrayorheatingplatebackwardsuntilbothplugs(g)areremovedfromthe
housing.Thenliftitandremovebackwards,diagonally.
13. Removethesidepanels(39).
Loosenthetwoscrews(34)onthebottomofthehousingandremovetheside
panels.
Function test that
can be performed
depend on the degree of
disassembly.
Thefollowing functiontestcanno wbedone:
• "Pressureandleakagechecks"onpage33
