KSB Delta Macro F User Manual

4 Description
25 of 92
KSB Delta Macro
1983.843/04-EN
1
B
4
3
1
2
B
Fig.11: Scope of supply, version L
1 Suction line (included in KSB’s scope of supply)
2 Lift check valve (included in KSB’s scope of supply)
3 Dry running protection (not included in KSB’s scope of supply)
4 Foot valve (not included in KSB’s scope of supply)
4.9 Dimensions and weights
For dimensions and weights refer to the outline drawing.
4.10 Terminal wiring diagram
For the terminal assignment refer to the circuit diagram.
4.11 Potential equalisation
A terminal marked with the earth symbol is provided at the power connection for
connecting a PE conductor.
