KSB Delta Macro
1983.843/04-EN
10.3 Messages
The following tables contain an overview of messages displayed by the control unit
in alternation with the current system status in the bottom right corner of the screen.
Some messages have to be reset manually.
10.3.1 Messages for specific pumps
In the range from 100 to 699 the first digit stands for the pump number. The pump
number can be between 1 and 6.
A message with the number 359, for example, indicates overload of the frequency
inverter of pump3.
Table38: Messages for specific pumps
ID
message
Parameter Description Status Reset mode
(factory
setting)
100 2-9-1-1 Failure motor circuit breaker pump 1 Warning Manual
101 2-9-1-2 Manual ON pump 1 Warning Auto
102 2-9-1-3 Manual OFF pump 1 Warning Auto
103 2-9-1-4 Over temperature motor pump 1 Alert Manual
150 2-9-2-1 Fault motor circuit breaker frequency inverter pump 1 Warning Manual
151 2-9-2-2 Fault frequency inverter pump 1 Alert Auto
152 2-9-2-3 Communication error frequency inverter pump 1 Alert Auto
153 2-9-2-4 Incorrect check sum frequency inverter pump 1 Alert Auto
154 2-9-2-5 Internal fault frequency inverter pump 1 Alert Auto
155 2-9-2-6 Mains fault frequency inverter pump 1 Alert Manual
156 2-9-2-7 Phase failure frequency inverter pump 1 Alert Manual
157 2-9-2-8 Overvoltage frequency inverter pump 1 Alert Auto
158 2-9-2-9 Undervoltage frequency inverter pump 1 Alert Auto
159 2-9-2-10 Overload frequency inverter pump 1 Alert Manual
160 2-9-2-11 Brake resistor frequency inverter pump 1 Alert Manual
161 2-9-2-12 Temperature fault frequency inverter pump 1 Alert Manual
162 2-9-2-13 AMA fault frequency inverter pump 1 Alert Manual
163 2-9-2-14 Short circuit frequency inverter pump 1 Alert Manual
164 2-9-2-15 Safety stop frequency inverter pump 1 Alert Manual
165 2-9-2-16 Configuration invalid frequency inverter pump 1 Alert Manual
200 2-9-3-1 Failure motor-circuit breaker pump 2 Warning Manual
201 2-9-3-2 Manual ON pump 2 Warning Auto
202 2-9-3-3 Manual OFF pump 2 Warning Auto
203 2-9-3-4 Excessive temperature motor pump 2 Alert Manual
250 2-9-4-1 Fault motor circuit breaker frequency inverter pump 2 Warning Manual
251 2-9-4-2 Fault frequency inverter pump 2 Alert Auto
252 2-9-4-3 Communication error frequency inverter pump 2 Alert Auto
253 2-9-4-4 Incorrect check sum frequency inverter pump 2 Alert Auto
254 2-9-4-5 Internal fault frequency inverter pump 2 Alert Auto
255 2-9-4-6 Mains fault frequency inverter pump 2 Alert Manual
256 2-9-4-7 Phase failure frequency inverter pump 2 Alert Manual
257 2-9-4-8 Overvoltage frequency inverter pump 2 Alert Auto
258 2-9-4-9 Undervoltage frequency inverter pump 2 Alert Auto
259 2-9-4-10 Overload frequency inverter pump 2 Alert Manual
260 2-9-4-11 Brake resistor frequency inverter pump 2 Alert Manual
261 2-9-4-12 Temperature fault frequency inverter pump 2 Alert Manual
262 2-9-4-13 AMA fault frequency inverter pump 2 Alert Manual
