Parameter Description Value range and dependencies Factory setting Access level Read Access level Write Re-start

required

1-2-1-2-21 Digital input 2 Control digital bit 1 Motor data Everybody Service -

1-2-1-2-22 Function input 1 [0] No operation Motor data Everybody Service -

[1] Reset

[10] Reversing

1-2-1-2-23 Function input 2 [0] No operation Motor data Everybody Service -

[1] Reset

[2] Coast inverse

1-2-1-2-24 Function input 3 [0] No operation Motor data Everybody Service -

[14] Jog

1-2-1-2-25 Function input 4 [0] No operation Motor data Everybody Service -

[2] Coast inverse

[16] Preset bit 0

1-2-1-2-26 Function Relay 1 [0] No operation Motor data Everybody Service -

[1] Control ready

[2] Drive ready

[4] Enable / no warning

[5] VLT running

[6] Running / no warning

[9] Alarm

[10] Alarm or warning

1-2-1-2-27 Function Relay 2 [0] No operation Motor data Everybody Service -

[1] Control ready

[2] Drive ready

[4] Enable / no warning

[5] VLT running

[6] Running / no warning

[9] Alarm

[10] Alarm or warning

1-2-1-2-28 Control site [0] Digital and control word Motor data Everybody Service -

[1] Digital only

[2] Control word only

1-2-1-2-29 Control timeout function [0] Off Motor data Everybody Service -

[1] Freeze output

KSB Delta Macro F User Manual
