RWCP, RWCN
17
9 Annexes
RWCP
Sectional C-1335
9.1 Sectional plans
Ref.
ENGLISH
102 Volute casing
135 Wear plate
138 Suction bell
160 Cover
161 Pump cover
211 Pump shaft
212 Intermediate drive shaft
230 Impeller
260 Impeller hub cup
301 Intermediate bearing
320 Bearing
341 Pedestal
344 Bearing housing lantern
360 Bearing cover
382 Bearing support
400 Gasket
411 Circular gasket
412 O-ring
420 Lip seal
422 Felt ring
433 Mechanical seal
452 Packing gland
458 Lantern ring
461 Packing
471 Mechanical seal cover
502 Wear ring
505 Retaining ring
520 Shaft sleeve
523 Shaft wearing sleeve
526 Centring sleeve
542 Throttling bush
545 Friction bearing bush
554 Flat washer
636 Grease nipple
711 Discharge pipe
712 Intermediate pipe
800 Motor
840 Coupling
844 Rigid coupling
867 Coupling flexible
890 Base plate
901 Hexagonal head screw
902 Bolt
903 Plug
904 Setscrew
914 Allen screw
920 Nut
923 Bearing nut
940 Key
800
902.1
920.1
554.1
341
840
867
422.1
360
923
914.1
902.2
920.2
554.2
382
320
526
422.2
902.3
920.3
554.3
890
554.4
920.4
902.4
712.1
212
940.1
636
914.2
420
940.2
554.1
1
711
520.1
940.4
520.2
940.5
920.9
901.1
400.3
102
411.2
903.2
400.4
554.10
901.2
844
940.3
545.1
904.1
301
554.5
920.5
902.5
712.2
211
545.2
902.6
920.6
554.6
344
904.2
545.3
161
902.7
920.7
554.7
400.2
230
260
914.3
135
412
411.1
903.1
400.1
554.8
920.8
902.8
1
38
