Ksenia lares series User Manual

19
EN
PARTITIONS
OUTPUTS
USB INTERFACE
Each input can be associated freely to a group (partition) in order to simplify its management. There are 8, 12 or 20
partitions available, depending on the model (see Table). For every partition, it is possible to program the entry, exit,
warning and patrol times and to dene a variety of switch-on and triggering methods.
The control panel PC board carries one supervised double-switching programmable 1A relay output and four 500mA
OC outputs. Depending on the model, the number of outputs can be extended up to a maximum of 128. Whether
the outputs are located on the control panel PC board or in the auxi module, each of them can be programmed
according to the requirements: polarity (normally open or normally closed); operation (bi-stable or mono-stable);
activation times (ON time and cycle time).
Outputs can be commanded in the following ways:
MODALITY HOW TO SWITCH ON
Automatic
• Zone events (alarms, tamper, by-pass, mask or real time)
• partition events (alarms, tamper, triggers, mask, bell, patrol, communication, entry time, advice, exit time,
management e negligency)
• Peripherals events (tamper or disapper)
• Timer / scheduler
• Networks loss/restore (power supply, Ethernet)/generic events
Manual
2
• Keystroke on ergo keypad
• Via webserver (keystroke on virtual keypad)
• Codes / keys
For more details please refer to Programming Manual.
All
lares systems have an “On-the-go” capable of connecting directly to the PC or to a USB ash-memory key. The
following table explains the differences.
PC As device
It’s a link between the PC and the system. Using basis SW you can congure
the system, update vocal messages, the FW of the main board and the
peripherals, read the real time of the zone and partitions.
USB Key As host
Using this link you can update the system conguration (after the key being
loaded via basis SW) or update vocal messages or FW (main and peripherals).
Use the Micro USB adapter - KSI7501000.020
2 See also lares and home automations.
ETHERNET CONNECTIVITY - LAN NETWORK
The Ethernet interface is already integrated in the PC board of the lares16 IP, lares48 IP and lares128 IP versions: this
solution allows managing the system easily via any internet connection from anywhere around the world.
ETHERNET Network Link
It’s a link between the PC and the system. Using basis SW you can congure the system, update vocal
messages, the FW of the main board and the peripherals, read the real time of the zone and partitions.
ETHERNET Network Link
Via web-server it’s possible:
• Display FW and SW versions, web-server and peripheral versions.
• Read and/or modify the name of the host and other network settings (DHCP, IP address, SMTP
parameters)
• Dynamic DNS
• Updating web-server pages
• Read and/or modify date and time
• Read event log and peripherals staus
• Display and switch on/off outputs.
• Display and arming/disarming of partiotions
• Display and by-pass/unby-pass zones
System is protected by a three-level security mechanism: all remote operations require PIN insertion, data are
encrypted before be sent on the network; last, remote access can be inhibited or limited by the user (i.e. can be
limited to real time or event logger reading only).
