KStar HPM3340 200k User Manual

23
Introduction
CAUTION!
The display provides more functions than those described in this
manual.
Output data Modules data
Detailed module data Input data
Battery data Status data
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
A B C
Phase Voltage(v) 220 221 221
Phase Current(A) 16 10 18
Frequency(H
Z) 50
Active Power(kw)
5.0 5.2 5.6
Apparent Power(KVA)
3.7 3.9 4.1
Load percent(%)
50 52 53
Load Peak Rate 1.3 1.5 1.8
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
Module01 Online
Module02 Online
Module03 Online
Module04 Online
Module05 Online
Module06 Offline
Module07 Offline
Module08 Offline
Module09 Offline
Module09 Offline
Module10 Offline
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
Module01
Invert Voltage(V) 220 220 220
Invert Current(A)
0 0 0
Frequency(HZ) 50
Positive Bus Voltage(V) 390
Negative Bus Voltage(V) 390
Code 8000-8000 D800-8000
0000-0000 0000-0000
Back
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
Mains A B C
Phase Voltage(V) 220 220 220
Phase Current(A)
2 2 2
Frequency(HZ)
50
Bypass
Phase Voltage(V)
220 220 220
Frequency(HZ) 50
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
Positive Battery Voltage (V) 239.9
Negative Battery Voltage (V) 241.0
Positive Battery Current (A) 15.1
Negative Battery Current (A)
14.8
Battery State Charge
Battery Temperature (
℃)
Lasting(min)
0
520KVA 23-05-2013
ID:01 08:00
◄
Output Module Input Batt State
►
Input Switch ON
Output Switch
ON
Bypass Switch OFF
Manu-Bypass Switch
OFF
Inside Temperature (
℃)
30
520KVA 23-05-2013
ID:01 08:00
◄ Setting Record Version ►
On-Line
On-Line
On-Line
On-Line
On-Line
On-Line
On-Line
Command
