Setting of single battery capacity Setting of max. Charge current
Setting of float base charge voltage Setting of Battery Protect Voltage
Setting of boost charge Setting of boost charge lasting time
Setting of boost Upper Limit Volt
4.3.2 UPS Module LCD display
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge Enable Back
Boost Last Time 231 Min
Max Charge Current 25A
Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge Enable Back
Boost Last Time 231 Min
Max Charge Current 25A Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge Enable Back
Boost Last Time 231 Min
Max Charge Current 25A Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge Enable Back
Boost Last Time 231 Min
Max Charge Current 25A
Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge Enable Back
Boost Last Time 231 Min
Max Charge Current 25A Next
On-Line
Float Base Volt.
▼ 2.28 ▲
Ensure Cancel
On-Line
Bat. Protect Volt.
▼ 1.28 ▲
Ensure Cancel
On-Line
Boost Charge
▼ Enable ▲
Ensure Cancel
On-Line
Boost Last Time
▼ 231 ▲
Ensure Cancel
On-Line
Boost Upper Limit Volt.
▼ 2.32 ▲
Ensure Cancel
