KStar HPM3340 200k User Manual

24
Command data
Setting data1
Setting data2 Setting data3
Setting data4 Record data
Version data Module detailed record data
Battery Test
Buzzer Set ON
Default Set
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Language/English
Change Password
Date Setting 2012-05-23 08:00
Back-Light Delay 10 min
Contrast 20
Self-Test Date disable
Timing of ON/OFF
disable Back
Next
520KVA 23-05-2013
ID:01 08:00
◄ Setting Record Version ►
Parallel ID 01
Float Volt Revise 0.001
Parallel Amount
04
Internal Module amount 05 Back
Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
Work Mode Paralle
System Voltage Level 220V
System Frequency Level
50HZ
Auto Turn-on
Enable
Bypass Frequency Range
10%
Bypass Volt. Upper Limit
15% Back
Bypass Volt. Lower Limit
-45%
O/P Volt Regulation 0%
Next
520KVA 23-05-2013
ID:01 08:00
◄ Setting Record Version ►
Single Battery Volt. 12V
Battery Number 20
Battery Group 1
Single Battery Capa. 100AH
Boost Upper Limit Volt. 2.31
Float Base Volt. 2.25
Battery Protect Volt. 1.70
Boost Charge
Enable Back
Boost Last Time
231 Min
Max Charge Current 25A
Next
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
0004 05-23 07:16:05 On Line
0002 05-23 07:16:01 Back Nomal
0003 05-23 07:06:00 Int.Input Switc..
0004 05-23 07:00:00 Int.Bypass Swit..
..
Back
Next
520KVA 23-05-2013
ID:01 08:00
◄ Setting Record Version ►
SYS Version: V02×10
LCD Version: 701×02F
520KVA 23-05-2013
ID:01 08:00
◄ Command Setting Record Version ►
On-Line
On-Line
On-Line
Command
On-Line
Command
On-Line
On-Line
Command
On-Line
ID:01 Record:0001 ▲
2013-12-21 15:00:25
Status:On Line ▼
Event: On Line
Alarm:
CODE:CC00-0000 DF00-0000 0000
0000-0000 0000-0000 Quit
