KTM 1290 SUPER ADVENTURE R User Manual

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 1290 SUPER ADVENTURE R Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Transmission	6-speed
Seat Height	880 mm
Weight (Dry)	221 kg
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Tire	90/90-21
Rear Tire	150/70-18
Power	160 hp (118 kW)
Torque	138 Nm
Fuel Tank Capacity	23 liters
Suspension Front	WP XPLOR 48 mm, adjustable
Suspension Rear	WP XPLOR PDS shock absorber
Clutch	PASC slipper clutch, hydraulically actuated
Frame	Chromoly steel trellis frame, powder coated
Front Brake	2 x Brembo 4-piston radial calipers, 320 mm discs
Rear Brake	267 mm disc, 2-piston caliper
Traction Control	MTC (Motorcycle Traction Control)
Wheelbase	1580 mm
ABS	Bosch 9.1 MP (Cornering-ABS and Offroad-ABS)
