Reel Carrier - 116 RT120Q Operator’s Manual
Set Up
Set Up
Adjust Arbor
1. Lower reel carrier.
2. Choose arbor position.
3. Turn ignition switch to STOP.
4. Install arbor (3) into spool.
5. Secure arbor into correct position.
Crushing weight. If load falls or moves it could kill or crush
you. Stay away.
Read operator’s manual. Follow safety rules and know
how to use all controls. Your safety is at stake.
273-475
NOTICE: Arbor position is
determined by weight of reel.
• Maximum weight of position 1 is
3000 lb (1361 kg).
• Maximum weight of position 2 is
2700 lb (1225 kg).
