Backhoe - 124 RT120Q Operator’s Manual
Finish Job
Finish Job
1. Raise stabilizers fully to engage latch.
2. Return remote throttle to low.
3. Lift boom while keeping dipper pointed at
ground (shown).
4. Curl bucket closed and move dipper fully
toward boom (shown).
5. Lift boom to highest position and latch
stow lock.
6. Lower boom slightly to engage lock.
7. Engage swing lock. See page 65.
IMPORTANT: For tractor to
function once operator has
returned to operator station,
stabilizers must be raised, remote
throttle must be set at low, and
boom must be stowed and locked.
