Controls - 34 RT120Q Operator’s Manual
Graphic Display
Graphic Display
The graphic display module shows engine RPM and has icons for other functions. Soft keys allow the
operator to toggle between various screens and functions.
Item Description Notes
Attachment speed Displays precentage of
attachment speed, and plow
or trencher/saw mode.
Note: Screen icons change according
to attachment being operated.
