54-0147
104
TracVision G4 Technical Manual
5.3 TracVision G4 Field
Replaceable Units
The TracVision G4 has been designed with durability and low
maintenance in mind. If you experience an operating problem or
otherwise require technical assistance, please contact your local
authorized TracVision G4 dealer/installer or distributor. If an
authorized dealer/installer or distributor is not located nearby,
contact KVH or KVH Europe directly at the telephone, fax, or
e-mail listings on the first page of this manual.
Replacement part numbers for field replaceable units (FRUs) that
can be serviced in the field are listed in Table 5-1. GyroTrac field
replaceable units are listed in Section 5.9, “GyroTrac Field
Replaceable Units” on page 117. These parts may be obtained from
any KVH authorized dealer/installer or may be ordered directly
from KVH.
FRU Part Number
Radome 02-0925-03
Main PCB 02-0992
RF PCB 02-1342
Antenna Gyro Sensor 02-1090
Antenna Gyro Gasket 24-0139
Elevation Drive Belt 24-0105-104
Elevation Motor 02-0994-02
North American LNB
†
02-0870
European LNB
††
02-1278
Data Cable 32-0619-50
†
32-0619-100
††
RF Cable 32-0417-50
†
PC Cable 32-0628-06
Power Cable 32-0510-50
Ground Cable 32-0583-50
CPU Fuses 16-0017-3150
†
North American system
††
European system
The serial number for your
TracVision G4 will be required
during any troubleshooting or
service calls. You will find the serial
number on the first page of this
manual.
Table 5-1
TracVision G4 Field
Replaceable Units
To help us continually improve the
quality and reliability of our
systems, please return any failed
component to KVH or KVH Europe
(care of the mailing address listed
on the first page of this manual)
after you receive your replacement
part.
