System Specifications
54-0147
123
Appendix A
System Specifications
A.1 Antenna Specifications
Physical Characteristics
Antenna Unit 21" (53 cm) h x 19.2" (49 cm) d;
30 lbs (13.6 kg)
External Sensor 7.8" (19.8 cm) l x 5" (12.7 cm) w x
5" (12.9 cm) h
ADCU 7.3" (18.5 cm) d x 8.2" (20.8 cm) w x
2.6" (6.6 cm) h
Operating temperature -25°C to +55°C (-13°F to +130°F)
Storage temperature -40°C to +85°C (-40°F to +185°F)
Input Power
Input 11-16 VDC @ 3.5 amps nominal
(4.5 amps peak)
Antenna System Performance
Minimum EIRP 50-51 dBW
Elevation range 15°- 85°
Azimuth range 720°
Pitch/roll range ±15°
Pitch/roll rate 45°/second
Turn rate 45°/second
Yaw ±90° in 10 seconds
Tracking rate 30° per second
Position repeatability 0.1°
Surge/sway/heave ±0.2 G
Shock 20 G, 11 msec
Vibration 0.9 G rms over 5-33 Hz
Table A-1
TracVision G4 Antenna
Physical Specifications
Table A-2
TracVision G4 Power Specifications
Table A-3
TracVision G4 Performance
Specifications

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KVH Industries TracVision G4 and is the answer not in the manual?

KVH Industries TracVision G4 Specifications

General IconGeneral
Operating Temperature-25°C to +55°C
Maximum Wind Speed Survival100 knots
TypeSatellite TV Antenna
Tracking TechnologyDigital
PolarizationLinear
Elevation Range10° to 80°
Frequency Range10.7-12.75 GHz
Maximum Wind Speed Operational50 knots
HumidityUp to 100%
CompatibilityDIRECTV, DISH Network
