Maintenance Port Parser Commands
54-0147
153
Enter Serial Number
Function: enters system serial number
Command: =SERNUM,XXXXXXXX
Where: XXXXXXXX = the system’s serial number
Response: SN = XXXXXXXX
Configure System
Function: configures software for a particular system model
Command: =TVXX
Where: XX = system model (i.e., G4)
Response: system configures software and antenna restarts
H.2 Manual Positioning Commands
To execute the following commands, first put the antenna unit in
idle mode by typing
HALT and pressing “ENTER.” Positioning
commands may be entered after the antenna comes to rest.
Azimuth Angle
Function: commands a manual azimuth angle that the
mechanism moves to
Command: AZ,XXXX (range is 0000-3599)
Argument: desired azimuth angle of the mechanism relative to
external magnetic reference, or baseplate fwd,
000°-359.9°
Response: echoes the command; mechanism moves at a
fixed velocity
Elevation Angle
Function: commands a manual elevation angle that the
mechanism moves to
Command: EL,XXX (range is 100-850)
Argument: desired elevation angle of the mechanism relative to
up, or external sensor attitude reference, 10.0°-
85.0°
Response: echoes the command; mechanism moves at a
fixed velocity
Table H-2
Manual Positioning Commands
