(4)
(2)
(3)
(5)
(6)
(7)(1)
INSTRUMENTS AND INDICATOR
(1) Multi-function display
(2) Left turn signal indicator
(3) High beam indicator
(4) Low oil level indicator lamp
(5) Right turn signal indicator
(6) Mode/Adjust button (A)
(7) Mode/Adjust button (B)
(1) Multi-function display
The display includes the following functions:
Speedometer
Odometer/Tripmeter
Digital clock
Fuel gauge
(2) Left turn signal indicator
Flashes when the left turn signal operates.
(3) High beam indicator
The ignition switch is at the " " position, the
high beam indicator lamp will light when the
headlight switch to select high beam ( ).
Both left and right turn signal indicator will flash
at the meantime when the hazard switch is
operated and turn signal switch is turned off.
NOTE:
The headlight can be turned on only when
the .engine is running
NOTE:
19
