To adjust the throttle limiter:
1. Loosen the lock nut (2).
2. Turn the throttle limiter screw (1) clockwise
to reduce throttle lever movement or
counterclockwise to increase throttle lever
movement.
3. Hole the screw in place and tighten the lock
nut.
73
SPEED LIMITER FOR NEW RIDERS
Your ATV has an adjustable throttle limiter.
The screw and locknut in the lower throttle
housing can be adjusted to limit throttle lever
movement.
(1) Adjuster
(2) Locknut
(1)
(2)
