(1)
(2)
(A)
(1) Adjuster
(2) Locknut
(A) 8mm(0.32in)
SPEED LIMITER
The speed limiter keeps the throttle from fully
opening, even when the throttle lever is
pushed to the maximum. Screwing in the
adjuster limits the maximum engine power
available and decreases the maximum speed
of the ATV.
POTENTIAL HAZARD
Improper adjustment of the speed limiter
and throttle.
WHAT CAN HAPPEN
The throttle cable could be damaged.
Improper throttle operation could result.
You could lose control, have an accident
or be injured.
HOW TO AVOID THE HAZARD
Do not turn the speed adjuster out more
than8mm(0.32in).
Always make sure the throttle lever free
play is adjusted to 1.0~4.0 mm (0.04~0.16
in). See page 96.
WARNING
32
