TRANSMISSION OIL
1. Transmission oil measurement
A. Place the machine on a level place.
B. Remove the oil filler bolt (1) and check
the oil level. It should be up to the brim
of the hole. If the level is low, add oil to
raise it to the proper level.
C. Reinstall the oil filler bolt and tighten to
specification.
(1) Oil filler bolt/measurement hole
(1)
Tightening torque
Oil filler bolt:
20 Nm (2 m-kg, 14 ft-lb)
89
