2. Transmission oil replacement
A. Place the machine on a level place.
B. Place a container under the engine.
C. Remove the oil filler bolt (1) and drain
plug (2) to drain the oil.
D. Reinstall the drain plug and tighten to
Specification.
E. Fill the engine with oil and install the oil
filler bolt.
Tightening torque
Drain plug:
20 Nm (2 m-kg, 14 ft-lb)
(1) Oil filler bolt/measurement hole
(2) Drain plug
(1)
(2)
Recommended oil : SAE #90
Oil quantity:
Periodic oil change:
0.11L (0.10Imp qt, 0.12US qt)
Total amount:
0.12L (0.11Imp qt, 0.13US qt)
Tightening torque
Oil filler bolt:
20 Nm (2 m-kg, 14 ft-lb)
90
