KYMCO ZING 150 - Assembly (Front Wheel)

11. FRONT WHEEL/SUSPENSION/
STEERING
11
-
8
ASSEMBLY
Pack all bearing cavities with grease. First
drive in the right bearing and then install the
distance collar. Finally, drive in the left
bearing.
Install the brake disk and tighten the five
nuts.
Apply grease to the dust seal and install the
dust seal.
Install the speedometer gearbox by aligning
the tabs with the grooves.
Apply grease to the speedometer gearbox and
dust seal, then install them to the wheel from
the left side.
Dust Seal
Dust Seal
Speedometer Cable
Attachment, 37x40mm
Brake Disk
Grooves
Tabs
Bearing Driver Handle
