9. CLUTCH/GEAR SHIFT MECHANISM
9
-
0
9
9
Friction Disk
Clutch Plate
Clutch Pressure
Plate
Clutch Outer Assembly
Clutch
Spring
Clutch Center
Clutch Lifter
Clutch Lifter
Guide Pin
