KYMCO ZING 150 - Handlebar

11. FRONT WHEEL/SUSPENSION/
STEERING
11
-
3
HANDLEBAR
REMOVAL
Remove the two throttle cover screws and
the throttle cover.
Disconnect the throttle cable from the
throttle grip and then remove the throttle
pipe from the handlebar.
Remove the two master cylinder holder bolts
and the master cylinder.
Remove the two left handlebar switch
housing screws, then separate and remove
the housing.
Remove the two clutch lever holder bolts and
the clutch lever holder.
Screws
Throttle Pipe
Throttle Cable
Bolts
Holder
Master Cylinder
Throttle Cover
Screws
