KYMCO ZING 150 - Front Wheel;Suspension; Steering

11. FRONT WHEEL/SUSPENSION/
STEERING
11
-
1
SERVICE INFORMATION
GENERAL INSTRUCTIONS
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Front axle shaft runout

0.2
Axial
0.5
2.0
Front wheel rim runout
Radial
0.5
2.0
Front fork s
pring free length
Front fork tube runout

0.2
Front fork oil capacity

TORQUE VALUES
Steering stem nut 6.0～9.0kg-m Front axle nut 5.5kg-m
Upper fork bridge bolt 0.9～1.3kg-m Front fork upper mount bolt 2.7kg-m
Master cylinder holder bolt 1.0kg-m Front fork lower mount bolt 2.3kg-m
Front brake disk nut 1.5kg-m
SPECIAL TOOLS
Steering stem driver
Steering stem wrench 5008422
Ball race remover
Bearing remover
Bearing remover head, 12m 5008416-03
Bearing remover head, 17m
Bearing driver handle
Attachment, 32x35mm
Attachment, 32x35mm
Attachment, 37x40mm
Fork seal driver
Pilot, 17mm
SERVICE INFORMATION..................... 11-1 FRONT WHEEL......................................11- 6
TROUBLESHOOTING............................ 11-2 FRONT FORK.........................................11-10
HANDLEBAR..........................................11-3 STEERING STEM................................... 11-14
