12. REAR WHEEL/BRAKE/SUSPENSION
12
-
1
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• When installing the drive chain joint clip, the cutout of the clip should be opposite to the rotating
direction.
• After the drive chain is adjusted, make sure that the rear brake pedal free play is normal and
adjust it if necessary.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Rear axle shaft runout

0.2
Axial

2.0
Rear rim runout
Radial

2.0
Rear brake drum I.D
130
131
Rear brake lining th
ickness
4.0
2.0
Rear shock absorber spring free length


TORQUE VALUES
Rear shock absorber upper mount nut 3.0～4.0kg-m
Rear shock absorber lower mount bolt 3.0～4.0kg-m
Rear axle nut 6.0～8.0kg-m
Rear fork pivot nut 5.5～6.5kg-m
Rear shock absorber damper nut 1.9～2.8kg-m
SPECIAL TOOLS
Bearing remover set 5008406-00-05
Pivot set
Remover handle
Block
Rear shock absorber attachment A
Rear shock absorber attachment
Attachment, 42x47mm
Pilot, 15mm
Rear shock absorber compressor 5008411
Bearing remover
Bearing remover, 15mm 5008416-05
SERVICE INFORMATION ..................... 12-1 REAR BRAKE ........................................12-4
TROUBLESHOOTING ............................ 12-2 REAR SHOCK ABSORBER ..................12-8
REAR WHEEL ......................................... 12-3 REAR FORK ...........................................12-9
