7. CYLINDER/PISTON
Inspect the top of the cylinder for warpage.
Service Limit: 0.05mm repair or replace if over
Measure the connecting rod small end I.D.
Service Limit: 15.032mm replace if over
Check the cam follower contact face for wear
or peeling of electroplated coating.
Measure the cam follower shaft I.D.
Service Limit: 12.05mm replace if over
