2P7/2R0/3PN
1-4-14
2340 Fuser pressure release
motor error
(Timeout)
The position detection sensor
is not detected continuously
for 30 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser pressure release motor and relay-L
PWB(YC11)
Relay-L PWB and engine PWB(YC2)
Defective drive
transmission sys-
tem of the fuser
pressure release
motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective fuser
pressure release
motor.
Replace the fuser pressure release motor.
Defective PWB. Replace the relay-L PWB or engine PWB.
(See Page 1-5-45,1-5-40)
2600 PF drive motor 1 error
(paper feeder 1)
When the PF drive motor is
driven, error signal is detected
continuously for 5 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 1 and PF main PWB (YC6)
Defective drive
transmission sys-
tem of the PF drive
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
Defective PF drive
motor.
Replace the PF drive motor 1.
Defective PF main
PWB.
Replace the PF main PWB (see page 1-5-
88).
2610 PF drive motor 2 error
(paper feeder 2)
When the PF drive motor is
driven, error signal is detected
continuously for 5 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 2 and PF main PWB (YC6)
Defective drive
transmission sys-
tem of the PF drive
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
Defective PF drive
motor.
Replace the PF drive motor 2.
Defective PF main
PWB.
Replace the PF main PWB (see page 1-5-
88).
Code Contents Causes
Check procedures/
corrective measures
