2PK/2PL/2PM/2PN-8
1-4-13
3500 CPU - ASIC (CCD PWB) communi-
cation error
An error code is detected.
Defective FFC
between CCD
PWB (YC1) and
control PWB
(YC8).
Replace the image scanner unit (ISU)
(See page 1-5-21).
Defective CCD
PWB.
Replace the CCD PWB.
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
4000 Polygon motor (laser scanner
unit) error
The polygon motor ready input is not
given for 6 s during the polygon
motor is ON.
Defective har-
ness between
polygon motor
and control PWB
(YC10), or
improper con-
nector insertion.
Reinsert the connector. Also check for
continuity within the connector har-
ness. If none, remedy or replace the
harness.
Defective laser
scanner unit.
Replace the laser scanner unit (See
page 1-5-17).
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
4200 BD error (laser scanner unit) error
After switching the resistor
SH_ZCNTPIN signal from Hi-Z to
signal output, APCSTATE did not
change to 32 within 1s.
BD sensor does
not detect laser
beam due to con-
densation on the
polygon mirror.
Turn machine power off for at least 30
minutes, then turn machine on again. If
not cured, replace the laser scanner
unit (See page 1-5-17).
Defective laser
scanner unit.
Replace the laser scanner unit (See
page 1-5-17).
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
4700 VIDEO ASIC device error
Mismatch between writing data and
reading data occurs eight times suc-
cessively.
When reading out, NACK was
detected five times in succession.
When writing, NACK was detected
five times in succession.
Defective con-
nector cable or
poor contact in
the connector.
Reinsert the connector. Also check for
continuity within the connector cable. If
none, replace the cable.
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
Code Contents
Remarks
Causes
Check procedures
/corrective measures
To Next Page
