Kyocera ECOSYS M2035dn Servlce Manual

2PK/2PL/2PM/2PN
1-4-14
6000 Broken Fuser heater wire
The fuser temperature does not rise
after the Fuser heater has been
turned on.
Poor contact in
the fuser therm-
istor connector
terminals.
Reinsert the connector (See page 1-5-
32).
Poor contact in
the Fuser heater
connector termi-
nals.
Reinsert the connector (See page 1-5-
32).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Fuser thermal
cutout triggered.
Replace the fuser unit (See page 1-5-
32).
Fuser heater
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Broken Fuser
heater wire.
Replace the fuser unit (See page 1-5-
32).
6020 Abnormally high fuser thermistor
temperature
Fuser thermistor detects abnormally
temperature.
When the temperature of a fuser
thermistor detects 195 °C or more at
the time of heater OFF and 155 °C
or more.
Shorted fuser
thermistor.
Replace the fuser unit (See page 1-5-
32).
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
6030 Broken fuser thermistor wire
Input from fuser thermistor is 0 (A/D
value).
Poor contact in
the fuser therm-
istor connector
terminals.
Reinsert the connector (See page 1-5-
32).
Broken fuser
thermistor wire.
Replace the fuser unit (See page 1-5-
32).
Fuser thermistor
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Fuser thermal
cutout triggered.
Replace the fuser unit (See page 1-5-
32).
Fuser heater
installed incor-
rectly.
Replace the fuser unit (See page 1-5-
32).
Broken Fuser
heater wire.
Replace the fuser unit (See page 1-5-
32).
Code Contents
Remarks
Causes
Check procedures
/corrective measures

Kyocera ECOSYS M2035dn Specifications

General

Secure printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	27.6 dB
Sound pressure level (copying)	51.3 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	65 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	439 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
