4-9
Printing from PC > Printing Data Saved on the Printer
Printing Documents from Private Print Box
In Private Printing, you can specify that a job is not to be printed until you operate the machine. When sending the job
from the application software, specify a 4-digit access code in the printer driver. The job is released for printing by
entering the access code on the operation panel, ensuring confidentiality of the print job. The data will be deleted upon
completion of the print job or after the power switch is turned off.
The following operations are possible:
Printing the Documents (page 4-9)
Deleting the Documents (page 4-10)
Printing the Documents
Print the documents stored in a Private Print box. The procedure is as follows.
1
Display the screen.
1 [Menu] key > [] [] key > [Job Box] > [] key > [] [] key > [Private/Stored] >
[OK] key
2 Select the creator of the document, and select the [OK] key.
2
Print the document.
1 Select the document to print.
[All Files] > [] [] key > [OK] key
To apply this process to all documents in Private/Stored Job, select [All Files].
2 Specify the number of copies to print as desired, and select the [OK] key.
Printing starts.
Upon completion of printing, the Private/Stored job is automatically deleted.
NOTE
If the document is protected by an access code, the password entry screen will be
displayed. Enter the password using the arrow keys, and then select [OK] key.
If you selected [All Files] and the access code does not match any of the documents,
and in addition there are no documents without access codes, "ID error" is displayed.
If you selected [All Files], select [] key after "Copies ---" is displayed to set the
number of copies.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS P6230cdn and is the answer not in the manual?

Kyocera ECOSYS P6230cdn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Time to first page (black, normal)6 s
Time to first page (color, normal)7 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Duplex print speed (black, normal quality, A4/US Letter)15 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Replacement cartridgesTK-5270Y, TK-5270C, TK-5270M, TK-5270K
Number of print cartridges-
Page description languagesPCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Paper input typeCassette, Paper tray
Total input capacity500 sheets
Total output capacity- sheets
Maximum input capacity2100 sheets
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesLegal, Letter, Plain paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfacesRJ-45, USB 2.0
Optional connectivityWireless LAN
Storage mediaHDD
Processor cores2
Processor modelA9
Processor familyARM Cortex
Maximum internal memory1000 MB
Internal storage capacity128 GB
Sound power level (standby)30 dB
Sound pressure level (printing)49.5 dB
CertificationTÜV/GS, CE
Product colorBlack, White
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (ready)56 W
Power consumption (standby)0.6 W
Power consumption (printing)466 W
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Weight and Dimensions IconWeight and Dimensions
Depth532 mm
Width390 mm
Height409.5 mm
