Page #126 background imageLoading...
Page #126 background image
5-3
Operation on the Machine > What is Document Box?
What is Document Box?
Document Box contains four types of component boxes which provide the following functions.
The following types of document boxes are available.
Custom Box (page 5-5)
Custom Box is a component box which you can create within the Document Box and store data for later retrieval. You
can create or delete a Custom Box, and manipulate data in various ways as described below:
Job Box
This is a box to save jobs executed from a PC.
Private Print/Stored Job Box (page 4-9
, page 4-11)
In Private Printing, you can specify that a job is not to be printed until you operate the machine. When sending the job
from the application software, specify a 4-digit access code in the printer driver. The job is released for printing by
entering the access code on the operation panel, ensuring confidentiality of the print job. The data will be deleted upon
completion of the print job or after the power switch is turned off.
In Stored Job, the print data sent from the application is saved to the machine. You can set up an access code as
necessary. If you set up an access code, enter the access code when printing. Print data will be stored in the Job Box
after printing. This will allow printing of the same print data repeatedly.
Quick Copy/Proof and Hold Box (page 4-13
, page 4-15)
Quick Copy feature facilitates additional prints of a document already printed. Activating Quick Copy and printing a
document using the printer driver allow the print data to be stored in the Job Box. When additional copies are required,
you can reprint the required number of copies from the operation panel. By default, up to 32 documents can be stored.
When power is turned off, all stored jobs will be deleted.
The Proof and Hold feature produces only a single proof print of multiple-print job and holds printing of the remaining
copies. Printing a multiple-print job in Proof and Hold using the printer driver allows only a single copy to be printed while
maintaining the document data in the Job Box. To continue to print the remaining copies, use the operation panel. You
can change the number of copies to print.
Creating a New Custom Box (page 5-5)
Storing Documents (page 5-5)
Printing Documents (page 5-6)
Editing Documents (page 5-6)
Deleting Documents (page 5-7)
Printing lists (page 5-8)
NOTE
To use Custom Box, an optional SSD must be installed in the machine.
NOTE
You can set up the machine so that temporary documents in job boxes are automatically deleted.
Delete (page 4-17)
For details on operating the Job Box, refer to the following:
Printing Data Saved on the Printer (page 4-8)
NOTE
When you attempt to store documents in excess of the above maximum, the oldest document data will be overwritten
by the latest document data.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS P6230cdn and is the answer not in the manual?

Kyocera ECOSYS P6230cdn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Time to first page (black, normal)6 s
Time to first page (color, normal)7 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Duplex print speed (black, normal quality, A4/US Letter)15 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Replacement cartridgesTK-5270Y, TK-5270C, TK-5270M, TK-5270K
Number of print cartridges-
Page description languagesPCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Paper input typeCassette, Paper tray
Total input capacity500 sheets
Total output capacity- sheets
Maximum input capacity2100 sheets
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesLegal, Letter, Plain paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfacesRJ-45, USB 2.0
Optional connectivityWireless LAN
Storage mediaHDD
Processor cores2
Processor modelA9
Processor familyARM Cortex
Maximum internal memory1000 MB
Internal storage capacity128 GB
Sound power level (standby)30 dB
Sound pressure level (printing)49.5 dB
CertificationTÜV/GS, CE
Product colorBlack, White
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (ready)56 W
Power consumption (standby)0.6 W
Power consumption (printing)466 W
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Weight and Dimensions IconWeight and Dimensions
Depth532 mm
Width390 mm
Height409.5 mm
